production line of XJM-type Flotation Machine

Payment Terms:	T/T
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Application: Ore

Brand Name: Fuwei

Type: Others

Mechanical stirring. Novel and unique way of feeding the pulp. Reasonable pulp flow large capacity.

XJM, XJX series of flotation machine belongs to self-suction stirring machine. It mainly used for separation of the coal below 0.5 mm, meanwhile the iron ore, phosphorus hydrochloric acid, lead, zinc ore effective equipments. Oblique deflection by double-impeller agitation, the pulp was a three-dimensional circle, pulp hill by the diversion center is expected to use aerosol Dosing methods and the use of negative pressure generated by the impeller rotation, self-priming agents into a mist of gas and air bubbles and contact with coal particles with a liquid automatic adjustment device with automatic control system to control the concentration of the volume of dry coal, and liquid delivery.
Features:
1.Mechanical stirring. Novel and unique way of feeding the pulp. Reasonable pulp flow large capacity.
2.Aeration efficiency is high, the adjustable range is wide, flotation speed. Boot condition, can adjust air inflow at will.
3.Mixing bodies with curved blades for the impeller and the steady flow radial board will enable the coal slurry circulation and moderate inflation.
4.For coal, grain size, concentration, and optimize the design parameters of fluid dynamics, high-density and thick, fine-grained coal has also been the effect of the ideal separation.
5.Compact, light weight, reliable operation. Flotation speed, fine-grained level of selective high-level coarse-grained effective flotation.
6.Drug consumption and low energy consumption, installed capacity and power consumption is less than the same type flotation machine with the specifications.
7.Structural parameters is reasonable, small footprint, taking into account of the compatibility with the old equipment.
8.Running high reliability, easy maintenance operations, pulp level single point of control, can automatically adjusted, but it can also be manual.
9.Impeller and the stator use wear-resistant materials, which service life is up 3 to 5 years.

Main Technical Parameter:

Technical Features/Type			XJM-S	XJM-S	XJM-S	XJM-S	XJX-T 8A	XJX-T8	XJX-T12
Handling Capacity			0.6-1.0	0.6-1.0	0.6-1.0	0.6-1.0	0.7-1.2	0.8-1.2	0.8-1.2
Single Volume			4	8	12	16	8.2	8.5	12
Electric Mixer	Type		Y200L-6	Y200L-6	Y2200M-6	Y250M-6	Y225M-6V6	Y225M-6V6	Y280S-8V1
	Power(kw)		22	22	30	37	30	30	37
	Speed		970	970	980	980	970	970	970
Scraper Body Reducer	Type		XWD1.5-4	XWD1.5-4	XWD1.5-4	XWD2.2-5	JXJ311-43	XWD2.2-5-1/43	JXJ311-43
	Power(kw)		1.5	1.5	1.5	2.2	1.94	2.2	1.94
	Speed		25	25	25	25	33.3	33.3	33.3
Dimensions	Length(mm)	3 Trough	6785	8200	9494.5	10970.5	12169	14744/15560	14258/15078
		4 Trough	8690	10555	122545	14175.5
		5 Trough	10595	12910	15014.5	17380.5
		6 Trough	12500	15265	17774.5	/
	Width(mm)		2150	2750	3120	3450	3500	3500	3840
	High(mm)		2758	2958	3458.5	3433	2950	2844	3500
Gross Weight (kg)	3 Trough		9684	15100	22863	27344	25.03	24.57/25.96	37.5/39
	4 Trough		12274	19758	28334	33966
	5 Trough		14854	24415	33805	40564
	6 Trough		17446	29072	39867	/
